Juno - LED Recessed Downlight (6" / Square) - 9.2W, 13.7W, 15.7W - 2700K, 3000K, 3500K, 4000K, 5000K, anf Warm Dim (2850K-1900K) Light Color - JPDZ6 SQDB ALO10 SWW5WD 90CRI
Quick Details
- Brand: Juno
- Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K, anf Warm Dim (2850K-1900K)
- CRI: 90
- Wattage: 9.2W, 13.7W, 15.7W
- Dimmable: Yes
- Life Rating: 50000 Hours
- Lumens: 700L, 1000L, 1200L
This product is a compatible replacement for:
Color Temperature, also known as Correlated Color Temperature or CCT, is a scale that helps describe how warm or cool light is. Light on the warm end of the spectrum is more yellow or orange like a candle. Light on the cool end of the spectrum is more blue like a sunny day.
We've grouped products into color temperature groups to help make finding the right product a little easier.
For a more detailed explanation of color temperature and how to choose the right color for your application, this is a helpful article
Color Rendering Index (CRI) is a specification used in lighting to help determine the quality of the light produced by a bulb. CRI is a number between 0 and 100, and the closer to 100, the better color should look under the light.
CRI is an approximation, so if color quality is critical for your lighting application, review this article
Dimmable products allow you to pair the product with a dimmer switch to smoothly lower the amount of light produced by a bulb or fixture.
The Juno JPDZ6 SQDB ALO10 SWW5WD is a canless low profile LED downlight designed for commercial applications such as offices, retail environments, and warehouses. It features a deeply regressed light source with patented color mixing technology, ensuring uniform light distribution and high color rendering. Available in multiple color temperatures including 2700K, 3000K, 3500K, 4000K, 5000K, and Warm Dim (2850K-1900K), it offers flexible lighting options for various settings. The fixture is dimmable to 3-10% with compatible controls and has an impressive 50,000-hour life rating. It has a diameter of 7.625 inches, a height of 2.81 inches, and is rated for wet locations, fitting into ceilings with a 6-inch square shape.
- Technology: LED, Deeply regressed light source with color mixing technology
- Light Output: 700, 1000, and 1200 lumens
- CRI: 90+
- Color Temperature: 2700K to 5000K, Warm Dim
- Dimming: Yes (to 3-10%) with compatible controls
- Rated Life: 50,000 hours
- Location Rating: Wet Location
- Size and Fit: 7.625-inch diameter, 2.81-inch height
MANUFACTURER INFORMATION |
|
| TYPE | LED Recessed Downlight (6" / Square) |
|---|---|
| SKU | JPDZ6 SQDB ALO10 SWW5WD 90CRI |
| CATALOG NUMBER | JPDZ6 SQDB ALO10 SWW5WD 90CRI 120 FRPC WWH M6 |
| BRAND | Juno |
| LIFE RATING | 50000 hrs. |
LIGHT CHARACTERISTICS |
|
| LIGHT TECHNOLOGY | LED |
| WATTAGE | 9.2W, 13.7W, 15.7W |
| CRI (COLOR RENDERING INDEX) | 90 |
| COLOR TEMPERATURE | 2700K, 3000K, 3500K, 4000K, 5000K, anf Warm Dim (2850K-1900K) |
| LIGHT OUTPUT (LUMENS) | 700L, 1000L, 1200L |
| BEAM TYPE | Medium Flood (MFL) |
| DIMMABLE | Yes |
ELECTRICAL REQUIREMENTS |
|
| INPUT VOLTAGE | 120 VAC |
COMPATIBILITY |
|
| LAMP ORIENTATION | Universal |
SHAPE & DIMENSIONS |
|
| SHAPE | Square |
| DIAMETER | 7.625 in. |
| HEIGHT | 2.81 in. |
| Gangs | 1 Gang |
MATERIAL & FINISH |
|
| FINISH | White |
COMPLIANCE |
|
| CALIFORNIA STATUS | Compliant (Purchasable) |
| COLORADO STATUS | Compliant (Purchasable) |
| HAWAII STATUS | Compliant (Purchasable) |
| ILLINOIS STATUS | Compliant (Purchasable) |
| MAINE STATUS | Compliant (Purchasable) |
| MARYLAND STATUS | Compliant (Purchasable) |
| MASSACHESETTS STATUS | Compliant (Purchasable) |
| MINNESOTA STATUS | Compliant (Purchasable) |
| NEVADA STATUS | Compliant (Purchasable) |
| NEW JERSEY STATUS | Compliant (Purchasable) |
| NEW YORK STATUS | Compliant (Purchasable) |
| OREGON STATUS | Compliant (Purchasable) |
| RHODE ISLAND STATUS | Compliant (Purchasable) |
| VERMONT STATUS | Compliant (Purchasable) |
| WASHINGTON STATUS | Compliant (Purchasable) |
| WASHINGTON DC STATUS | Compliant (Purchasable) |
